Brand Name : ZSHONORHIGH, Finsboard
Model Number : LSY-8LD
Certification : CE,ROHS,FCC,PSE,CCC,ATEX, ISO9001,BSCI
Place of Origin : Chinese Mainland
MOQ : 100pcs
Price : Negotiable
Payment Terms : T/T, Western Union
Supply Ability : 5000pcs/month
Delivery Time : 25-30days or confirm
Packaging Details : Box package+ bubble or as customized
Product name : RFSL-02 Module Street Light Highway Lighting
Power : 50W/100W150W/200W/250W/300W
LED : SMD3030
Input voltage : AC85-265V
Material : Aluminum+ clear pc
Housing : SKD Housing
Usage : Outdoor,Road,Highway, Garden,Square
Lamp Luminous Efficiency(lm/w) : 100-130lm/w
Feature
The LSY-8LD series of outdoor LED luminaires sets a new standard for robust performance, exceptional energy efficiency, and unparalleled versatility in a wide array of public and commercial spaces. Engineered to illuminate vast areas with clarity and reliability, this lighting solution is ideal for demanding applications such as Highways, Parking Lots, Beach Volleyball courts, Roadways, Gardens, and public Squares. Its comprehensive design caters to the diverse needs of urban infrastructure and recreational facilities, promising superior visibility and significant operational advantages.
One of the most compelling advantages of the LSY-8LD is its extensive range of power options, allowing for highly customizable lighting solutions. Available in six distinct wattage configurations—50W, 100W, 150W (forming Group 1, 2, 3 respectively), and a higher tier of 200W, 250W, 300W (comprising Group 4, 5, 6)—this series ensures that specifiers and project managers can select the precise light output required for any given application. This scalability guarantees optimal illumination levels, preventing both over-lighting and under-lighting, thereby maximizing energy efficiency and visual comfort. Correspondingly, the luminaires come in various compact sizes, from 36530580mm for lower wattages to 76030580mm for higher powers, all maintaining a streamlined profile that simplifies installation and integrates aesthetically into diverse outdoor environments.
| Model | LSY-8LD | ||
| Power | 50W | 100W | 150W |
| Size(mm) | 365*305*80 | 440*305*80 | 520*305*80 |
| Group number | 1 | 2 | 3 |
| Power | 200W | 250W | 300W |
| Size(mm) | 600*305*80 | 680*305*80 | 760*305*80 |
| Group number | 4 | 5 | 6 |
| Material | Aluminum+pc | ||
| Driver | AC85-310V/AC100-277V/DC180-260V,PF0.95 | ||
| IP Rating | IP65 | ||
| Light Efficiency | 130-140lm/w | ||
| Warranty | 2/3 years | ||
| Application | Outdoor,Highway,Parking Lot,Beach Volleyball,Roadway Garden,Square | ||








|
|
